YFP Series direct connected Fans and Pumps motors
YFP Series Documentation
High efficiency and energy saving IE2 & IE3
Low noise
Little vibration
Reliable performance
Directly couple with the equipments which can withstand axial load, such as pumps, fans.
Common frame size corresponding to the power:
|
Frame Size |
80 |
90 |
100 |
112 |
132 |
160 |
180 |
200 |
225 |
250 |
280 |
315 |
355 |
|
Power range kW |
0.18~1.1 |
0.37~2.2 |
0.75~3 |
1.5~4 |
2.2~7.5 |
4~18.5 |
11~22 |
15~37 |
18.5~45 |
30~55 |
37~110 |
45~220 |
110~375 |
|
Poles |
2.4.6.8 |
2.4.6.8 |
2.4.6.8 |
2.4.6.8 |
2.4.6.8 |
2.4.6.8 |
2.4.6.8 |
2.4.6.8 |
2.4.6.8 |
2.4.6.8 |
2.4.6.8 |
2.4.6.8.
10 |
2.4.6.8.
10 |
Remark: For the other special rated powers, please contact with us.
B35 Foot and B5 Flange Mounted
V1 Vertical Shaft down Footless Flange Mounted
